Some XML helpers to help with OOXML development

Note

These are all based around xml-js and output that modules internal format

API

asXmlElement

When working with xml-js it's really handy to not have to worry about when you're passing an XML string our the xml-js JSON type called Element

This helper function just outputs an Element for either input

asXmlElement("<name>foo</name>") // => {name: "name", text: "foo"}
asXmlElement({name: "name", text: "foo"}) // => {name: "name", text: "foo"}

Note

All the other functions in this document that accept XML, also accept this Element (using this function)

safeXml

An XML tagged template literal with the following features

• error if XML is incorrect
• array support in substitution

The following will error in development, because of mismatched start/end tags

safeXml`<foo>hello</bar>`

Substitution of arrays "just works" so you can map values in the tagged template literals

const items = [1,2,3].map(n => safeXml`<name>item ${1}</name>`);
const outXml = safeXml`<test>${items}</test>`
assert.equal(outXml, `<test><name>item 1</name><name>item 2</name><name>item 3</name></test>`);

This also makes it easy to support https://prettier.io/docs/en/options#embedded-language-formatting

compact

Removes non required whitespace from the XML

const outXml = compact(`
    <test>
        something
    </test>
`);
assert.equal(outXml, "<test>something</test>");

removeFragments

For XML to be valid, there must be a single root node. When composing apps it's handy for that not to be true.

For example the following would error

const xml = safeXml`
    <name>foo</name>
    <name>bar</name>
`

So instead we'd like something like a HTML fragment

const xml = safeXml`
    <XML_FRAGMENT>
        <name>foo</name>
        <name>bar</name>
    </XML_FRAGMENT>
`

So we did just that, removeFragments walks over a tree removing <XML_FRAGMENT>...</XML_FRAGMENT> nodes.

const innerBit = safeXml`
    <XML_FRAGMENT>
        <name>foo</name>
        <name>bar</name>
    </XML_FRAGMENT>
`
const newXml = removeFragments(
    safeXml`
        <doc>
            ${innerBit}
        </doc>
    `
)
assert.equal(newXml, `
    <doc>
        <name>foo</name>
        <name>bar</name>
    </doc>
`)

cdata

From the wikipedia page

CDATA section is a piece of element content that is marked up to be interpreted literally, as textual data, not as marked-up content.

But <name><![CDATA[one < two]]><name> is ugly and hard to read, so instead

safeXml`<name>${cdata("one < two")}</name>`

CI

License

MIT
