The Bin Packing Problem (BPP)

In the BPP, a collection of items must be stored in the minimum possible number of bins. In this case, the items have a weight associated and the bins are restricted to carry a maximum weight. This problem has many real-world applications such as loading trucks with a weight restriction, container scheduling, or design of FPGA chips. In terms of complexity, the BPP is an NP-hard problem and its formulation is given by

$$ \min \sum_{j=1}^m y_j,\tag{1} $$

subject to:

$$ \sum_{i=1}^n w_i x_{ij} \le W y_j \qquad \forall j=1 \dots m, \tag{2} $$

$$ \sum_{j=1}^m x_{ij} = 1 \qquad \forall i = 1 \dots n, \tag{3} $$

$$ x_{ij}\in {0,1} \qquad \forall i=1 \dots n \qquad \forall j=1 \dots m, \tag{4} $$

$$ y_{j}\in {0,1} \qquad \forall j=1 \dots m, \tag{5} $$

where $n$ is the number of items (nodes), $m$ is the number of bins, $w_{i}$ is the i-th item weight, $W$ is the bin capacity, $x_{ij}$ and $y_j$ are binary variables that represent if the item $i$ is in the bin $j$, and whether bin $j$ is used or not, respectively. From the above equations, Eq.(1) is the cost function to minimize the number of bins, Eq.(2) is the inequality constraint for the maximum weight of a bin, Eq.(3) is the equality constraint to restrict that an item is only in one of the bins, and Eqs.(4) and (5) means that $y_i$ and $x_{ij}$ are binary variables.
