Setting layer name shown under the layer control

[giswqs]

Is it possible to set the layer name shown under the layer control? Currently, it seems the default layer name is empty. I tried using l.name = 'layer name', but it has no effect. It would be great if the da.leaflet.plot() has a name argument that can be set directly. Thanks.

[davidbrochart]

Thanks for your suggestion @giswqs, I will try to work on it soon. Maybe we could use the DataArray name? Similarly, plotting a Dataset (#2) would use each array's name.

[giswqs]

@davidbrochart Sounds good. So basically, users can set da.name, then your da.leaflet.plot() function automatically uses da.name as the layer name to show under the layer control. Am I correct?

da = xr.open_rasterio('/path/to/file')
da.name = 'layer name'
l = da.leaflet.plot(m, x_dim='x', y_dim='y')

[davidbrochart]

Yes, that's the plan. But it could also be possible to set it as a keyword argument of the plot function in the case of a DataArray as you suggested.

[giswqs]

Sounds great! Looking forward to it. I will be adding xarray_leaflet as a dependency for geemap. I plan to add a function (e.g., Map.add_raster(file_path, layer_name)) that wraps da.leaflet.plot() so that users can use one line of code to load local raster datasets to geemap.

[davidbrochart]

Awesome!

[giswqs]

I was able to customize the layer name. Here is the source code.

[davidbrochart]

So it looks like setting the layer name works fine?

[giswqs]

Yes, it works with geemap. But I would still suggest you add the layer_name argument to the plot() function so that non-GEE users can still use ipyleaflet to load rasters. Otherwise, when multiple local raster layers are added, only the last one added will be listed under the layer control.

[crendl]

I would still suggest you add the layer_name argument to the plot() function

I second that suggestion!
Regards

[davidbrochart]

Sorry, I didn't have much time to work on xarray-leaflet lately. There will be a JupyterCon sprint on ipyleaflet, where we could also work on xarray-leaflet. It would be great if you could participate!

[davidbrochart]

The layer name is now set to the DataArray name (see davidbrochart@66536e0).
